UFX7000A AWGN Noise Generator

Datasheet

Abstract

The Noisecom UFX7000A broadband AWGN noise generator has a powerful single board computer with flexible architecture used to create complex custom noise signals for advanced test systems. This versatile platform allows the user to meet their most challenging design requirements. Precision components provide high output power with superior flatness, and the flexible computer architecture allows control of multiple attenuators, switches, and filter banks.

UFX 7000A Programmable Noise Generator Series



The Noisecom UFX7000A broadband AWGN noise generator has a powerful single board computer with flexible architecture used to create complex custom noise signals for advanced test systems. This versatile platform allows the user to meet their most challenging design requirements. Precision components provide high output power with superior flatness, and the flexible computer architecture allows control of multiple attenuators, switches, and filter banks.

The standard RF configuration includes a broadband noise source and noise path attenuator with a maximum attenuation range of 127 dB in 1 dB steps. Additional attenuation ranges, and step sizes are available. Optional filters can be specified in any combination of low pass, high pass, band pass, or band reject. Combined with advanced switching circuitry, the designer can create many different path combinations. The signal output connectors can be located on the front, or rear panel to provide convenient customer access on the bench, or in a rack system. An optional signal combiner, and signal attenuator allow independent control of the noise & signal paths to vary SNR while BER testing.

The unit has a touch-screen TFT display, mouse, and keyboard for manual control, or standard Ethernet for ATE remote control. Optional IEEE 488.2 GPIB and RS232 remote interfaces are also available. If there are additional requirements for your noise application, please contact the factory for more information about custom designs.

General Specifications



  • Output White Gaussian noise
  • Output power up to +30 dBm
  • 127 dB of attenuation; 1 dB step size
  • Optional 0.1 dB step size
  • Units > 2 GHz have total attenuation of 79.9 dB
  • Low distortion signal path
  • Noise attenuator accuracy:
    ±0.2 dB or 0.5% at 1 – 500 MHz
    ±0.2 dB or 1% at 0.5 – 1.0 GHz
    ±0.3 dB or 2% at 1 – 2 GHz
  • Standard connectors SMA female
  • 6.25” color VGA, TFT touch screen
  • Dimensions: 17.25 in. wide x 6.50 in. including feet, high x 19.50 in. deep
  • Fold-down feet for bench top use
  • Power 115 VAC, 60 Hz
  • Operating Temperature: -10° to +65°C


figure 1Custom filter control menu

figure 2 Intuitive standard control menu



figure 3

Specifications

UFX7000A Series Output Characteristics
Model

Frequency Band

Power

dBm / Hz (dBm)

Flatness (dB)

uV / root (Hz)

UFX7101A

10 Hz - 20 kHz

+13

-30

±0.5

 7071

UFX7103A

10 Hz - 500 kHz

+13

-44

±0.5

 1414

UFX7105A

10 Hz - 10 MHz

+13

-57

±0.5

 316

UFX7107A

100 Hz - 100 MHz

+13

-67

±0.75

 100

UFX7108A

100 Hz - 500 MHz

+10

-77

±1.0

 31.6

UFX7109A

100 Hz - 1 GHz

+10

-80

±1.5

 22.4

UFX7110A

100 Hz - 1.5 GHz

+10

-82

±1.5

 18.2

UFX7111A

1 GHz - 2GHz

+10

-80

±1.5

 22.4

UFX7112A

1 MHz - 2 GHz

0

-93

±2.0

 5.01

UFX7113A

10 MHz - 3 GHz

0

-95

±2.5

 5.01

UFX7114A

10MHz to 4 GHz

-7

-103

±2.5

1.58

UFX7124A

2 GHz - 4 GHz

-10

-103

±2.0

 1.58

UFX7116A

10 MHz - 6 GHz

-12

-110

±3.0

0.71

UFX7126A

2 GHz - 6 GHz

-14

-110

±2.5

 0.71

UFX7128A

10 MHz - 10 GHz

-17

-117

±3.5

 0.3251

UFX7218A

2 GHz - 18 GHz

-20

-122

±2.0

 0.18

UFX7240A

2 GHz - 40 GHz

-20

-126

±4.0

 0.11


UFX7900A Series (1 Watt output) Output Characteristics
Model

Frequency Band

Power

dBm/Hz

Flatness (dB)

UFX7903A

500 Hz - 500 kHz

+30

-27

±2

UFX7905A

500 Hz - 10 MHz

+30

-40

±2

UFX7907A

250 kHz - 100 MHz

+30

-50

±2

UFX7908A

1 MHz - 200 MHz

+30

-53

±2

UFX7909A

1 MHz - 300 MHz

+30

-55

±2

UFX7910A

2 MHz - 500 MHz

+30

-57

±2

UFX7911A

5 MHz - 1 GHz

+30

-60

±3

Applications



  • Eb/No, C/N, SNR
  • Disk Drive Testing
  • BER Testing
  • Military Jamming
  • GPS Receiver Testing
  • CATV Testing
  • Spectrum Analyzer Calibration
  • Filter Testing
  • EMI Testing

figure 4

Option number Description
U7opt01 N female output connector
U7opt02 BNC female output connector
U7opt03 0 to 127.9 dB noise attenuator in 0.1 dB steps instead of 127 dB in 1 dB steps 1
U7opt04 Switch elements, 2 X SP6T for 4 filter paths, 1 thru-path, 1 termination (filters optional)
U7opt06 75 Ohm output impedance (6 dB loss in the noise path and 12 dB loss in the signal path)
U7opt07 Combiner for input signal (6 dB loss in noise and signal paths)
U7opt08 Double output terminals (switched)
U7opt09 Custom frequency, power, or flatness requirement 3
U7opt10 Line power 230 VAC, 50 Hz
U7opt11 RS-232 interface
U7opt12 0 to 127 dB signal attenuator in 1 dB steps 2
U7opt12x  0 to 127 dB signal attenuator in 1 dB steps 4
U7opt13 0 to 127.9 dB signal attenuator in 0.1 dB steps 2 7
U7opt13x  0 to 127 dB signal attenuator in 0.1 dB steps 4
U7opt15 Optional 19” rack mount brackets
U7opt16 GPIB IEEE-488
U7opt17 Removable storage media security option 4
U7opt18; 3U High Enclosure 6
U7opt19 Pulsed Noise Generator

1 0 to 79.9 for UFX7124A, UFX7126A, UFX7128A & UFX7240A
   NOTE: For UFX7240A, this option reduces output power by 2dB, flatness of ±6 dB,
   Power -136 dBm/Hz (-30 dBm).
2 Requires opt7, signal combiner
3 Consult factory for pricing and availability
4 UFX7113A only
5 Highly recommended for military
6 Must be included at time or original order
7 0 to 79.9 for UFX7124A, UFX7126A, UFX7128A
   "N/A" for UFX7240A
